CPU Prozessor AMD Athlon 500 MHz AMD-K7500MTR51B C FSB200 512KB Slot A* c931

Technische Daten

Type

CPU / Microprocessor

Market segment

Desktop

Family

AMD Athlon

CPU part number

AMD-K7500MTR51B C is an OEM/tray microprocessor

Frequency

500 MHz

Bus speed

200 MHz

Clock multiplier

5

Package

Card Module; 5.51" x 2.467" (14 cm x 6.27 cm)

Socket

Slot A

Introduction date

23-Jun-99

Price at introduction

$324

Architecture / Microarchitecture

Microarchitecture

K7

Processor core

Argon (Model 1)

Manufacturing process

0.25 micron; 22 million transistors

Die

184mm2

Data width

32 bit

The number of CPU cores

1

The number of threads

1

Floating Point Unit

Integrated

Level 1 cache size

64 KB 2-way set associative code cache; 64 KB 2-way set associative data cache

Level 2 cache size

512 KB backside cache running at 250 MHz

Multiprocessing

Uniprocessor

Features

MMX instructions; Extensions to MMX; 3DNow! technology; Extensions to 3DNow!

Low power features

Halt state; Stop Grant states; Sleep state, Probe state

Electrical / Thermal parameters

V core

1.6V ± 0.1V

Minimum/Maximum operating temperature

0°C - 70°C

Minimum/Typical/Maximum power dissipation

6 Watt (Stop Grant mode) / 38 Watt / 42 Watt

Notes on AMD Athlon 500 MHz

Actual bus frequency is 100 MHz. Because the processor uses Double Data Rate bus the effective bus speed is 200 MHz.
