CPU Prozessor AMD Athlon 64 3000+ ADA3000DAA4BP FSB1000 512KB Sockel 939* c60

Technische Daten

Type

CPU / Microprocessor

Market segment

Desktop

Family

AMD Athlon 64

Model number

3000+

CPU part numbers

ADA3000DAA4BP is an OEM/tray microprocessor; ADA3000BPBOX is a boxed microprocessor with fan and heatsink

Stepping codes

ABBLE   CBBLE   LBBLE   YBBLE

Frequency

3000+ (rated); 1800 MHz (real)

Bus speed

One 1000 MHz 16-bit HyperTransport link (2GT/s)

Clock multiplier

9

Package

939-pin lidded organic microPGA; 1.57" x 1.57" (4 cm x 4 cm)

Socket

Socket 939

Architecture / Microarchitecture

Microarchitecture

K8

Processor core

Venice

Core stepping

DH-E3

CPUID

20FF0

Manufacturing process

0.09 micron silicon-on-insulator (SOI) technology

Data width

64 bit

The number of CPU cores

1

The number of threads

1

Floating Point Unit

Integrated

Level 1 cache size

64 KB 2-way set associative instruction cache; 64 KB 2-way set associative data cache

Level 2 cache size

512 KB exclusive 16-way set associative cache

Physical memory

1 TB

Virtual memory

256 TB

Multiprocessing

Uniprocessor

Features

MMX instructions, Extensions to MMX, 3DNow! technology, Extensions to 3DNow!, SSE / Streaming SIMD Extensions, SSE2 / Streaming SIMD Extensions 2, SSE3 / Streaming SIMD Extensions 3, AMD64 / AMD 64-bit technology, EVP / Enhanced Virus Protection

Low power features

Halt state, Stop Grant state, Cool'n'Quiet technology

Memory controller

The number of controllers: 1
Memory channels: 2
Supported memory: DDR-400
Maximum memory bandwidth (GB/s): 6.4

Other peripherals

One 16-bit HyperTransport link

Electrical / Thermal parameters

V core

1.35V / 1.4V

Maximum operating temperature

49°C - 65°C

Thermal Design Power

67 Watt

Notes on AMD Athlon 64 3000+ (rev. E3)

In the minimum performance state (P-state) the processor runs at 1000 MHz and 1.1 Volt core voltage. Thermal Design Power in the minimum P-state is 29.6 Watt
