CPU Prozessor AMD Athlon 64 3500+ ADA3500DAA4BN FSB1000 512KB L2 Sockel 939*c692

Technische Daten

Type

CPU / Microprocessor

Market segment

Desktop

Family

AMD Athlon 64

Model number

3500+

CPU part numbers

ADA3500DAA4BN is an OEM/tray microprocessor; ADA3500BNBOX is a boxed microprocessor with fan and heatsink

Frequency

3500+ (rated); 2.2 GHz / 2200 MHz (real)

Clock multiplier

11

Package

939-pin lidded organic microPGA; 1.57" x 1.57" (4 cm x 4 cm)

Socket

Socket 939

Architecture / Microarchitecture

Instruction set

x86

Microarchitecture

K8

Processor codename

San Diego

Core stepping

SH-E4

CPUID

20F71

Manufacturing process

0.09 micron silicon-on-insulator (SOI) technology

Data width

64 bit

The number of CPU cores

1

The number of threads

1

Floating Point Unit

Integrated

Level 1 cache size

64 KB 2-way set associative instruction cache; 64 KB 2-way set associative data cache

Level 2 cache size

512 KB 16-way set associative exclusive cache

Physical memory

1 TB

Virtual memory

256 TB

Multiprocessing

Uniprocessor

Extensions & Technologies

MMX instructions; Extensions to MMX; 3DNow! technology; Extensions to 3DNow!; SSE / Streaming SIMD Extensions; SSE2 / Streaming SIMD Extensions 2; SSE3 / Streaming SIMD Extensions 3; AMD64 / AMD 64-bit technology

Security Features

EVP / Enhanced Virus Protection

Low power features

Halt state; Stop Grant state; Cool'n'Quiet technology

Integrated peripherals / components

Memory controller

The number of controllers: 1
Memory channels (per controller): 2
Memory channels (total): 2
Supported memory: DDR

Other peripherals

One 16-bit HyperTransport link with speeds up to 1000 MHz

Electrical / Thermal parameters

V core

1.35V / 1.4V

Maximum operating temperature

49°C - 65°C

Thermal Design Power

67 Watt

Notes on AMD Athlon 64 3500+ (rev. E4, BN)

In the minimum performance state (P-state) the processor runs at 1000 MHz and 1.1 Volt core voltage. Thermal Design Power in the minimum P-state is 27.5 Watt
