HD9750WCGHBOX is a boxed microprocessor with fan and heatsink
Stepping codes
JAAAB AA JAAFB AA JAAHB AA
Frequency ?
2400 MHz
Bus speed ?
One 1800 MHz 16-bit HyperTransport link (3.6 GT/s)
Clock multiplier ?
12
Package
940-pin organic micro-PGA
Sockets
Socket AM2 Socket AM2+
Introduction date
Mar 27, 2008
Price at introduction
$215
Architecture / Microarchitecture
Microarchitecture
K10
Platform
Cartwheel (mainstream platform with AMD 780G chipset) Spider (performance platform with AMD 790FX/790GX chipsets)
Processor core ?
Agena
Core stepping ?
DR-B3
CPUID
100F23
Manufacturing process
0.065 micron silicon-on-insulator (SOI) technology 450 million transistors
Die size
285mm2
Data width
64 bit
The number of CPU cores
4
The number of threads
4
Floating Point Unit
Integrated
Level 1 cache size ?
4 x 64 KB 2-way set associative instruction caches 4 x 64 KB 2-way set associative data caches
Level 2 cache size ?
4 x 512 KB 16-way set associative caches
Level 3 cache size
2 MB 32-way set associative shared cache
Multiprocessing
Uniprocessor
Features
MMX instructions
Extensions to MMX
3DNow! technology
Extensions to 3DNow!
SSE / Streaming SIMD Extensions
SSE2 / Streaming SIMD Extensions 2
SSE3 / Streaming SIMD Extensions 3
SSE4a ?
AMD64 / AMD 64-bit technology ?
EVP / Enhanced Virus Protection ?
AMD-V / AMD Virtualization technology
Low power features
Cool'n'Quiet 2.0
CoolCore technology ?
Independent Dynamic Core Technology ?
Dual Dynamic Power Management ?
Core C1 and C1E states
Package S1, S3, S4 and S5 states
Integrated peripherals / components
Integrated graphics
None
Memory controller
The number of controllers: 1 Memory channels: 2 Channel width (bits): 72 Supported memory: DDR2-1066 DIMMs per channel: up to 2 Maximum memory bandwidth (GB/s): 17.1
Other peripherals
HyperTransport 3.0 technology
Electrical / Thermal parameters
V core ?
1.15V - 1.25V
V NorthBridge
1.25V
Maximum operating temperature ?
55°C - 70°C
Thermal Design Power ?
95 Watt
Notes on AMD Phenom X4 9750 (95W)
On socket AM2+ platforms in the minimum performance state the processor runs at 1200 MHz / 1.05 Volt core voltage, and has TDP 56.9 Watt
On socket AM2 platforms in the minimum performance state the processor runs at 1200 MHz / 1.15 - 1.25 Volt core voltage, and has TDP 65.3 Watt
