Products description
Asus K8V-MX/S Mainboard
Original FSC/Yakumo Ersatzteil !!! Aber auch als Ersatz für andere Fabrikate geeignet, wenn die Boards ähnlich sind.
FireWire IEEE1394 * FSB 800 * DDR 400 * 1x AGP 8x * 5.1 Audio * bis zu 8x USB2.0 * LAN * und vieles mehr!!!
Technische Daten:
CPU
- Socket 754 for AMD Athlon 64 / Sempron
- AMD Cool 'n' Quiet
Chipset
- VIA K8M800
- VIA VT8237R
Front Side Bus
- 1600MT/s
Memory
- 2 x DIMM, max. 2GB, DDR400/ 333/ 266, ECC, non-ECC, un-buffered memory
Expansion Slots
- 1 x AGP8X
- 3 x PCI
VGA
-Integrated Graphics
Storage/RAID
- 2 x Serial ATA, RAID 0, RAID 1, JBOD
- 2 x UltraDMA 100/66/33
Audio
- ADI AD1888 SoundMAX 6-channel CODEC
- S/PDIF out interface
LAN
- Realtek RTL8201CL 10/100M LAN PHY
USB
- Max 8 USB2.0 ports
Special Features
- Adjustable FSB/DDR ratio, Fixed AGP/PCI frequencies
- ASUS C.P.R.
- ASUS MyLogo2
- SFS (Stepless Frequency Selection) from 200MHz up to 240MHz at 1MHz increment
Back Panel I/O Ports
- 1 x Parallel
- 1 x Serial
- 1 x PS/2 Keyboard
- 1 x PS/2 Mouse
- 1 x VGA
- 1x FireWire IEEE1394
- 1 x Audio I/O
- 1 x RJ45
- 4 x USB
Internal I/O Connectors
- 2 x USB connector supports additional 4 USB ports
- 24-pin ATX Power connector
- 4-pin ATX 12V Power connector
- CD / AUX audio in
- Chassis Intrusion
- CPU / Chassis FAN connectors
- Front panel audio connector
- S/PDIF out connector
BIOS
- 4 Mb Flash ROM, AMI BIOS, (TCAV), PnP, DMI2.0, WfM2.0, SM BIOS 2.3, ASUS EZ Flash, ASUS CrashFree BIOS 2
Manageability
- WfM 2.0, DMI 2.0, WOR, WOL by PME, WOR by PME, WO USB, WO KB/MS
Form Factor
- mATX, 9.6”x 9.6”(24.5cm x 24.5cm)
Lieferumfang
Das Mainboard inkl. Blende * ohne weiteres Zubehör * gebraucht *
Abbildung ähnlich
