MSI MS-7504 Ver1.0 Mainboard +Blende Sockel 775 FSC OEM VGA DDR2 LAN Audio*m1080

MSI MS-7504 Ver 1.0 Mainboard + Blende Sockel 775 FSC OEM VGA DDR2 LAN Audio

Technische Daten

CPU

Intel® CoreTM 2 Quad, CoreTM 2 Duo, Pentium® and Celeron® processors in the LGA775 package

1333MHz FSB supported

Chipset

NVIDIA® MCP73PV single chipset

Main Memory

DDR2 533 / 667 / 800 SDRAM (240pin / 1.8V); 2 x DDR2 DIMMs (Max. 4GB)

Slots

1 x PCI Express x16 slot

1 x PCI Express x1 slot

2 x PCI slots, support 3.3V / 5V PCI bus Interface

Storage

4 x SATA ports by NVIDIA® MCP73PV for up to four SATA devices

Supports storage and data transfers at up to 3Gb/s

SATA1~4 support RAID 0 / 1 / 5 / 0+1 mode

LAN

Supports 10 / 100 / 1000 Gigabit Ethernet LAN by Realtek® RTL 8211BL

IEEE 1394

Chip integrated by VIA® VT6308P; Transfer rate is up to 400Mbps

Audio

Chip integrated by Realtek® ALC888S

Flexible 8-channel audio with jack sensing

Compliant with Azalia 1.0 Spec

Interne I/O Anschlüsse       Echtzeituhr/Kalender mit Batteriepufferung

4 x SATA2 Connectors for up to 4 SATA Devices

1 x 4-pin CPU FAN Connector

1 x 4-pin System FAN Connector

1 x JSPI2 Flash Connector

1 x JAudio1 Front Audio Connector

1 x JSPD1 SPDIF Connector

1 x JFP1 Front Panel Connector

1 x JFP2 Power LED / Internal Speaker Connector

1 x IEEE1394 Firewire Connector

1 x CMOS Jumper

2 x USB2.0 Connectors für 4 weitere optionale USB Ports

1 x Buzzer

1 x 24-pin ATX Power Connector

1 x 4-pin 12V Processor Power Supply Connector

Rückseite I/O Panel

1 x Optical SPDIF

1 x Coaxial SPDIF

1 x IEEE1394 Firewire

6 x USB2.0

1 x VGA

1 x RJ-45 LAN

8-ch Audio jacks 6 x 3,5 mm Klinke

BIOS

The mainboard BIOS provides “Plug & Play” BIOS which detects the peripheral devices and expansion cards of the board automatically. The mainboard provides a Desktop Management Interface (DMI) function which records your mainboard specifications. Modified and Adapted AMIBIOS by Fujitsu.

Dimension

Micro ATX Form Factor; ca. 24.4cm x 24.4cm

Mounting

8 mounting holes

Lieferumfang

Das Mainboard inkl. Blende * ohne weiteres Zubehör * gebraucht *

Abbildung ähnlich
