CPU Prozessor AMD Athlon 650 MHz AMD-K7650MTR51B C

AMD Athlon 650 MHz AMD-K7650MTR51B C

General information
Type	CPU / Microprocessor
Market segment	Desktop
Family	AMD Athlon
CPU part number	AMD-K7650MTR51B C is an OEM/tray microprocessor
Frequency ?	650 MHz
Bus speed ?	200 MHz
Clock multiplier ?	6.5
Package	Card Module
Socket	Slot A
Introduction date	9-Aug-99
Price at introduction	$849
Architecture / Microarchitecture
Microarchitecture	K7
Processor core ?	Argon (Model 1)
CPUID	612
Manufacturing process	0.25 micron 22 million transistors
Die size	184mm²
Data width	32 bit
The number of CPU cores	1
The number of threads	1
Floating Point Unit	Integrated
Level 1 cache size ?	64 KB 2-way set associative code cache 64 KB 2-way set associative data cache
Level 2 cache size ?	512 KB backside cache running at 325 MHz
Multiprocessing	Uniprocessor
Features	MMX instructions Extensions to MMX 3DNow! technology Extensions to 3DNow!
Low power features	Halt state Stop Grant states Sleep state ? Probe state
Integrated peripherals / components
Integrated graphics	None
Electrical / Thermal parameters
V core ?	1.6V ± 0.1V
Minimum/Maximum operating temperature ?	0°C - 70°C
Minimum/Typical/Maximum power dissipation	6 Watt (Stop Grant mode) / 48 Watt / 54 Watt
Notes on AMD Athlon 650 MHz
Actual bus frequency is 100 MHz. Because the processor uses Double Data Rate bus the effective bus speed is 200 MHz.
