CPU Prozessor AMD Sempron 2200+ SDA2200DUT3D Sockel 462 A FSB333 braun* c201

Technische Daten

Type

CPU / Microprocessor

Market segment

Desktop

Family

AMD Sempron

Model number

2200+

CPU part numbers

SDA2200DUT3D is an OEM/tray microprocessor; SDA2200BOX is a boxed microprocessor with fan and heatsink

Stepping codes

BCXJB   BIXJB

Frequency

2200+ (rated); 1500 MHz (actual)

Bus speed

333 MHz

Clock multiplier

9

Package

453-pin organic PGA; 1.95" x 1.95" (4.95 cm x 4.95 cm)

AMD Package numbers

27648; 28104

Socket

Socket 462 / Socket A

Introduction date

July 28, 2004

Price at introduction

$39

Architecture / Microarchitecture

Instruction set

x86

Microarchitecture

K7

Processor codename

Thoroughbred (Model 8)

CPUID

681

Manufacturing process

0.13 micron

Data width

32 bit

The number of CPU cores

1

The number of threads

1

Floating Point Unit

Integrated

Level 1 cache size

64 KB instruction cache; 64 KB data cache

Level 2 cache size

Full speed on-die 256 KB

Multiprocessing

Uniprocessor

Extensions & Technologies

MMX instructions; Extensions to MMX; 3DNow! technology; Extensions to 3DNow!; SSE / Streaming SIMD Extensions

Low power features

Halt state; Stop Grant states; Sleep state; Probe state

Electrical / Thermal parameters

V core

1.6V

Minimum/Maximum operating temperature

0°C - 90°C

Typical/Maximum power dissipation

55.9 Watt / 62 Watt

Notes on AMD Sempron 2200+ (Thoroughbred)

Actual bus frequency is 166 MHz. Because the processor uses Double Data Rate bus the effective bus speed is 333 MHz
