CPU Prozessor AMD Athlon 64 3000+ ADA3000AEP5AP FSB800 1MB Cache Sockel 754* c63

General information

Type

CPU / Microprocessor

Market segment

Desktop

Family

AMD Athlon 64

Model number  ?

3000+

CPU part number

• ADA3000AEP5AP is an OEM/tray microprocessor

Stepping code

CBAUC

Frequency  ?

3000+ (rated)
1800? MHz (real)

Clock multiplier  ?

9

Package

754-pin lidded microPGA
1.57" x 1.57" (4 cm x 4 cm)

Socket

Socket 754

Architecture / Microarchitecture

Microarchitecture

K8

Core stepping  ?

CG

Manufacturing process

0.13 micron silicon-on-insulator (SOI) technology

Data width

64 bit

The number of CPU cores

1

The number of threads

1

Floating Point Unit

Integrated

Level 1 cache size  ?

64 KB 2-way set associative instruction cache
64 KB 2-way set associative data cache

Level 2 cache size  ?

1 MB exclusive 16-way set associative cache

Physical memory

1 TB

Virtual memory

256 TB

Multiprocessing

Uniprocessor

Features

• MMX instructions
• Extensions to MMX
• 3DNow! technology
• Extensions to 3DNow!
• SSE / Streaming SIMD Extensions
• SSE2 / Streaming SIMD Extensions 2
• AMD64 / AMD 64-bit technology  ?
• EVP / Enhanced Virus Protection  ?

Low power features

• Halt state
• Stop Grant state  ?

Integrated peripherals / components

Integrated graphics

None

Memory controller

The number of controllers: 1
Memory channels: 1
Supported memory: DDR

Other peripherals

One 16-bit HyperTransport link with speeds up to 800 MHz

Electrical / Thermal parameters

V core  ?

1.5V

Maximum operating temperature  ?

70°C

Thermal Design Power  ?

89 Watt
