Products description
CPU Prozessor AMD Athlon 64 3400+ ADA3400AEP4AX
FSB800 512K Sockel 754
Technische Daten | |
Type | CPU / Microprocessor |
Market segment | Desktop |
Family | AMD Athlon 64 |
Model number | 3400+ |
CPU part numbers | ADA3400AEP4AX is an OEM/tray microprocessor; ADA3400AXBOX is a boxed microprocessor with fan and heatsink |
Stepping codes | ABASC CBAEC CBASC CBAXC CBAZC LBAZC |
Frequency | 3400+ (rated); 2400 MHz (real) |
Clock multiplier | 12 |
Package | 754-pin lidded microPGA; 1.57" x 1.57" (4 cm x 4 cm) |
AMD Package number | 27962 |
Socket | Socket 754 |
Architecture / Microarchitecture | |
Microarchitecture | K8 |
Processor core | NewCastle |
Core stepping | DH-CG |
CPUID | FC0 |
Manufacturing process | 0.13 micron silicon-on-insulator (SOI) technology |
Data width | 64 bit |
The number of CPU cores | 1 |
The number of threads | 1 |
Floating Point Unit | Integrated |
Level 1 cache size | 64 KB 2-way set associative instruction cache; 64 KB 2-way set associative data cache |
Level 2 cache size | 512 KB exclusive 16-way set associative cache |
Physical memory | 1 TB |
Virtual memory | 256 TB |
Multiprocessing | Uniprocessor |
Features | MMX instructions, Extensions to MMX, 3DNow! technology, Extensions to 3DNow!, SSE / Streaming SIMD Extensions, SSE2 / Streaming SIMD Extensions 2, AMD64 / AMD 64-bit technology, EVP / Enhanced Virus Protection |
Low power features | Halt state, Stop Grant state, Cool'n'Quiet technology |
Memory controller | The number of controllers: 1 |
Other peripherals | One 16-bit HyperTransport link with speeds up to 800 MHz |
Electrical / Thermal parameters | |
V core | 1.5V |
Maximum operating temperature | 70°C |
Thermal Design Power | 89 Watt |
Notes on AMD Athlon 64 3400+ (rev. CG, AX) | |
In the minimum performance state (P-state) the processor runs at 1000 MHz and 1.1 Volt core voltage. Thermal Design Power in the minimum P-state is 22 Watt | |
Lieferumfang
CPU - ohne weiteres Zubehör * gebraucht *
Abbildung ähnlich
