CPU Prozessor AMD Athlon A1400AMS3C 1400MHz 1.4GHz

AMD Athlon A1400AMS3C

General information
Type	CPU / Microprocessor
Market segment	Desktop
Family	AMD Athlon
CPU part number	A1400AMS3C is an OEM/tray microprocessor
Stepping codes	AYHJA AYHJAR EYHJA FYHJA
Frequency ?	1400 MHz
Bus speed ?	266 MHz
Clock multiplier ?	10.5
Package	453-pin staggered ceramic PGA 1.95" x 1.95" (4.95 cm x 4.95 cm)
AMD Package number	27016
Socket	Socket A (Socket 462)
Introduction date	6-Jun-01
Price at introduction	$253
Architecture / Microarchitecture
Microarchitecture	K7
Processor core ?	Thunderbird (Model 4)
Manufacturing process	0.18 micron 37 million transistors
Die	120mm2
Data width	32 bit
The number of CPU cores	1
The number of threads	1
Floating Point Unit	Integrated
Level 1 cache size ?	64 KB 2-way set associative code cache 64 KB 2-way set associative data cache
Level 2 cache size ?	Full-speed on-die 256 KB
Multiprocessing	Uniprocessor
Features	MMX instructions Extensions to MMX 3DNow! technology Extensions to 3DNow!
Low power features	Halt state Stop Grant states Sleep state ? Probe state
Integrated peripherals / components
Integrated graphics	None
Electrical / Thermal parameters
V core ?	1.75V ± 0.1V
Minimum/Maximum operating temperature ?	0°C - 95°C
Minimum/Typical/Maximum power dissipation	5 Watt (Stop Grant mode) / 64.7 Watt / 72.1 Watt
Notes on AMD Athlon 1.4 GHz
Actual bus frequency is 133 MHz. Because the processor uses Double Data Rate bus the effective bus speed is 266 MHz.
