CPU Prozessor AMD Athlon XP 1900+ AX1900DMT3C FSB2

AMD Athlon XP 1900+ AX1900DMT3C

General information
Type	CPU / Microprocessor
Market segment	Desktop
Family	AMD Athlon XP
Model number ?	1900+
CPU part number	AX1900DMT3C is an OEM/tray microprocessor
Stepping codes	AGNGA AGOGA AGOIA
Frequency ?	1900+ (rated) 1600 MHz (real)
Bus speed ?	266 MHz
Clock multiplier ?	12
Package	453-pin organic PGA 1.95" x 1.95" (4.95 cm x 4.95 cm)
AMD Package number	27111
Socket	Socket A (Socket 462)
Introduction date	5-Nov-01
Price at introduction	$269
Architecture / Microarchitecture
Microarchitecture	K7
Processor core ?	Palomino (Model 6)
Manufacturing process	0.18 micron copper process
Die size	129.26mm² (total) 105.72mm² (without L2 cache)
Data width	32 bit
The number of CPU cores	1
The number of threads	1
Floating Point Unit	Integrated
Level 1 cache size ?	64 KB code 64 KB data
Level 2 cache size ?	Full-speed on-die 256 KB
Multiprocessing	Uniprocessor
Features	MMX instructions Extensions to MMX 3DNow! technology Extensions to 3DNow! SSE / Streaming SIMD Extensions
Low power features	Halt state Stop Grant states Sleep state ? Probe state
Integrated peripherals / components
Integrated graphics	None
Electrical / Thermal parameters
V core ?	1.75V
Minimum/Maximum operating temperature ?	0°C - 90°C
Minimum/Typical/Maximum power dissipation	2 Watt (Stop Grant mode) / 60.7 Watt / 68 Watt
Notes on AMD Athlon XP 1900+ (Palomino)
Actual bus frequency is 133 MHz. Because the processor uses Double Data Rate bus the effective bus speed is 266 MHz.
