AMD Duron 700MHz D700AUT1B

General information
Type	CPU / Microprocessor
Market segment	Desktop
Family	AMD Duron
CPU part number	D700AUT1B is an OEM/tray microprocessor
Stepping codes	AKBA AKCA AMCA
Frequency ?	700 MHz
Bus speed ?	200 MHz
Clock multiplier ?	7
Package	453-pin staggered ceramic PGA 1.95" x 1.95" (4.95 cm x 4.95 cm)
AMD Package numbers	26822, 27016
Socket	Socket A (Socket 462)
Introduction date	19-Jun-00
Price at introduction	$192
Architecture / Microarchitecture
Microarchitecture	K7
Processor core ?	Spitfire (Model 3)
Manufacturing process	0.18 micron 25 million transistors
Data width	32 bit
The number of CPU cores	1
The number of threads	1
Floating Point Unit	Integrated
Level 1 cache size ?	64 KB code 64 KB data
Level 2 cache size ?	on-die 64 KB exclusive cache
Multiprocessing	Uniprocessor
Features	MMX instructions Extensions to MMX 3DNow! technology Extensions to 3DNow!
Low power features	Halt state Stop Grant states Sleep state ? Probe state
Integrated peripherals / components
Integrated graphics	None
Electrical / Thermal parameters
V core ?	1.6V ± 0.1V
Minimum/Maximum operating temperature ?	0°C - 90°C
Typical/Maximum power dissipation	28.2 Watt / 31.4 Watt
Notes on AMD Duron 700 MHz
Actual bus frequency is 100 MHz. Because the processor uses Double Data Rate bus the effective bus speed is 200 MHz.
