CPU AMD Athlon 64 X2 4200+ ADA4200IAA5CU 2x2.2GHz Dual Core Sockel AM2* c351

Technische Daten

Type

CPU / Microprocessor

Market segment

Desktop

Family

AMD Athlon 64 X2

Model number

4200+

CPU part numbers

ADA4200IAA5CU is an OEM/tray microprocessor; ADA4200CUBOX is a boxed microprocessor with fan and heatsink

Stepping codes

ADB4F   CDB4F   LDB4F   LEDBF   NDB4F   NDBBF   NDBEF

Frequency

4200+ (rated); 2200 MHz (real)

Bus speed

One 1000 MHz 16-bit HyperTransport link (2GT/s)

Clock multiplier

11

Package

940-pin organic micro Pin Grid Array (micro-PGA)

Socket

Socket AM2

Architecture / Microarchitecture

Microarchitecture

K8

Processor core

Windsor

Core stepping

F2

Manufacturing process

0.09 micron silicon-on-insulator (SOI) technology; 164 million transistors

Data width

64 bit

The number of CPU cores

2

The number of threads

2

Floating Point Unit

Integrated

Level 1 cache size

2 x 64 KB 2-way set associative instruction caches; 2 x 64 KB 2-way set associative data caches

Level 2 cache size

2 x 512 KB 16-way set associative exclusive caches

Physical memory

1 TB

Virtual memory

256 TB

Multiprocessing

Uniprocessor

Features

MMX instructions, Extensions to MMX, 3DNow! technology, Extensions to 3DNow!, SSE / Streaming SIMD Extensions, SSE2 / Streaming SIMD Extensions 2, SSE3 / Streaming SIMD Extensions 3, AMD64 / AMD 64-bit technology, EVP / Enhanced Virus Protection, AMD-V / AMD Virtualization technology

Low power features

Cool'n'Quiet technology, Halt state, Stop Grant state

Memory controller

The number of controllers: 1
Memory channels: 2
Supported memory: DDR2-800
Maximum memory bandwidth (GB/s): 12.8

Other peripherals

HyperTransport 2.0 technology (1 link)

Electrical / Thermal parameters

V core

1.3V / 1.35V

Maximum operating temperature

55°C - 70°C

Thermal Design Power

89 Watt

Notes on AMD Athlon 64 X2 4200+ (Socket AM2, 89W, rev. F2)

In the minimum performance state (P-state) the processor runs at 1000 MHz and 1.1 Volt core voltage. Thermal Design Power in the minimum P-state is 34.7 Watt
