CPU AMD Athlon 64 X2 5400+ ADO5400IAA5DO Dual Core FSB1000 2 x 1MB Sockel AM2

Technische Daten
Type	CPU / Microprocessor
Market segment	Desktop
Family	AMD Athlon 64 X2
Model number	5400+
CPU part numbers	ADO5400IAA5DO is an OEM/tray microprocessor; ADO5400DOBOX is a boxed microprocessor with fan and heatsink
Stepping codes	AAA9G CAA9G NAA9G NAAFG NAAIG NAAWG
Frequency	5400+ (rated); 2.8 GHz / 2800 MHz (real)
Bus speed	One 1000 MHz 16-bit HyperTransport link (2 GT/s)
Clock multiplier	14
Package	940-pin organic microPGA
Socket	Socket AM2
Architecture / Microarchitecture
Instruction set	x86
Microarchitecture	K8
Platform	Cartwheel
Processor codename	Brisbane
Core stepping	BH-G2
CPUID	60FB2
Manufacturing process	0.065 micron silicon-on-insulator (SOI) technology; 221 million transistors
Data width	64 bit
The number of CPU cores	2
The number of threads	2
Floating Point Unit	Integrated
Level 1 cache size	2 x 64 KB instruction caches; 2 x 64 KB data caches
Level 2 cache size	2 x 512 KB
Physical memory	1 TB
Virtual memory	256 TB
Multiprocessing	Uniprocessor
Extensions & Technologies	MMX instructions; Extensions to MMX; 3DNow! technology; Extensions to 3DNow!; SSE / Streaming SIMD Extensions; SSE2 / Streaming SIMD Extensions 2; SSE3 / Streaming SIMD Extensions 3; AMD64 / AMD 64-bit technology; AMD-V / AMD Virtualization technology
Security Features	EVP / Enhanced Virus Protection
Low power features	Cool'n'Quiet technology; Halt state; Stop Grant state
Integrated peripherals / components
Memory controller	The number of controllers: 1 Memory channels (per controller): 2 Memory channels (total): 2 Supported memory: DDR2-800
Other peripherals	HyperTransport 2.0 technology
Electrical / Thermal parameters
V core	1.3V / 1.35V
Maximum operating temperature	55°C - 68°C
Thermal Design Power	65 Watt
Notes on AMD Athlon 64 X2 5400+ (65W, non-BE)
Core voltage and maximum temperature are likely the same as for other 65 Watt processors with G2 (DO) stepping: 1.325 / 1.35 / 1.375 Volt and 55 - 68 degrees Celsius
